Cylinder base gasket 0.3mm Rotax (1)

The cylinder head cap Rotax 10 mm (engraved 1.8 torque) is a spare part of origin manufacturer (Original Rotax Racing). It is designed to tightly seal one of the threaded cylinder head orifices (cylinder cover) on all the engines of the range Rotax 125 Max (Micro, Mini, Junior, Max Senior, Max Master and DD2).

Machined according to strict micrometric tolerances, this brass plug or high strength alloy has a thread of 10 mm. Its flat head includes plant engraving "1.8 Torque", indicating the pilots and mechanics the regulatory torque recommended by the plant (1.8 N · m) not to damage the aluminum thread of the cylinder head. This plug ensures absolute sealing of the liquid cooling circuit, avoiding any pressure drop or heat transfer leak at high speed.

The BTR M6x25mm screw (or chc - hollow hex cylindrical screw) is one of the most used hardware on the engines Rotax. Its length of 25 mm and its thread M6 Make it a versatile screw, mainly used for the assembly of the housings, to the attachment of certain periphery accessories or the maintenance of internal components depending on the version of your engine.

The Circular membrane spring (70 x 1.7 x 0.3 mm) is the metal voltage ring that ensures the maintenance and tightness of the orange bellows base on the valve body. Its precise dimensions ensure a uniform pressure on the entire circumference of the membrane, condition sine qua non to the proper functioning of the pneumatic system.

The Red cylinder head (ref. Rotax 211225) is the upper structural element that closes the high engine cooling circuit. Real visual signature of engines RotaxThis injected aluminum alloy part is designed to withstand the most intense thermal and vibratory stresses, ensuring the overall waterproofing of the water chamber.

TheFull valve box Rotax EVO20is an original manufacturer part designed for motors Rotax from 2020. It ensures optimum intake management of the air/fuel mixture and ensures proper operation and engine performance.

This version corresponds to engines equipped with the EVO 2020 configuration.

The valve box cover, commonly called intake blowjob, is a centerpiece of your engine intake system Rotax. This model, with a connecting diameter of 42.5 mm, is designed to perfectly accommodate the dell'orto VHSB 34 carburetor.

The Cylinder head Rotax MAX / DD2 is the red upper piece that seals the high engine. She is 100% compatible with the entire 125cc range from Rotax, including direct socket motors (MAX) and two-speed engines (Dd2). It ensures the circulation of the coolant around the combustion dome for perfect thermal stability.

The M8 Stop Washer (N ° 21) is a security technical washer placed between the nut and the cylinder base. Its role is to prevent any inconvenient loosening of the high engine mount nuts. On the DD2 motor, where the vibrations and transmission stresses are important, it is essential to ensure the integrity of the motor block.

The 64x2mm O-ring is the internal seal located between the dome of the cylinder head and the cylinder. Its precise dimensions (64 mm inner diameter and 2 mm thick) are designed to fit perfectly into the cylinder groove, preventing the cooling liquid from seeping into the combustion chamber.
