Taptite screw M4x8mm Rotax (46)

The cylinder head cap Rotax 10 mm (engraved 1.8 torque) is a spare part of origin manufacturer (Original Rotax Racing). It is designed to tightly seal one of the threaded cylinder head orifices (cylinder cover) on all the engines of the range Rotax 125 Max (Micro, Mini, Junior, Max Senior, Max Master and DD2).

Machined according to strict micrometric tolerances, this brass plug or high strength alloy has a thread of 10 mm. Its flat head includes plant engraving "1.8 Torque", indicating the pilots and mechanics the regulatory torque recommended by the plant (1.8 N · m) not to damage the aluminum thread of the cylinder head. This plug ensures absolute sealing of the liquid cooling circuit, avoiding any pressure drop or heat transfer leak at high speed.

The Support spring is housed between the valve piston and the black adjustment cap. Its role is to exercise a constant reminder force on the guillotine to keep it in the low position. It is the resistance of this spring that defines when (which engine speed) the pressure of the gases will be able to lift the valve to release the power.

The Cylinder head Rotax MAX / DD2 is the red upper piece that seals the high engine. She is 100% compatible with the entire 125cc range from Rotax, including direct socket motors (MAX) and two-speed engines (Dd2). It ensures the circulation of the coolant around the combustion dome for perfect thermal stability.

The Circular membrane spring (70 x 1.7 x 0.3 mm) is the metal voltage ring that ensures the maintenance and tightness of the orange bellows base on the valve body. Its precise dimensions ensure a uniform pressure on the entire circumference of the membrane, condition sine qua non to the proper functioning of the pneumatic system.

idem for Evo

spare parts origin

The M8 Stop Washer (N ° 21) is a security technical washer placed between the nut and the cylinder base. Its role is to prevent any inconvenient loosening of the high engine mount nuts. On the DD2 motor, where the vibrations and transmission stresses are important, it is essential to ensure the integrity of the motor block.

Cylinder head cover Rotax Max not painted

The Red cylinder head (ref. Rotax 211225) is the upper structural element that closes the high engine cooling circuit. Real visual signature of engines RotaxThis injected aluminum alloy part is designed to withstand the most intense thermal and vibratory stresses, ensuring the overall waterproofing of the water chamber.

The valve box cover, commonly called intake blowjob, is a centerpiece of your engine intake system Rotax. This model, with a connecting diameter of 42.5 mm, is designed to perfectly accommodate the dell'orto VHSB 34 carburetor.

ROTAX Micro/Mini exhaust flange MAX Ø 22mm

Rotax Screw BTR M6x16mm
