Full description: Reliability and assembly
Why use certified hardware Rotax rather than standard hardware?
-
Resistance class 8.8: This standard ensures that the screw can support the clamping stresses and thermal expansion of the motor block without lying or breaking.
-
Elzn Treatment: This specific zinc is avoiding the phenomenon of "cold welding" between screw steel and the aluminum of the housing, thus facilitating the future dismal.
-
Partial thread (FP): The smooth part of the screw allows perfect centering and a better distribution of clamping forces on the walls of the housings.
-
Quality BTR Footprint: The hollow hex is machined precisely to prevent your key from ripe, even after multiple maintenance cycles.
💡 Michel's trick
"Guys, a crankcase screw, it respects it! We do not hug themselves with a low-end key. My advice: use a torque. On the aluminum of Rotax, the couple recommended is 10 nm. If you tighten too hard, you will crack the housing thread, and there is the insured helical! A small mesh of copper fat on the thread before mounting, and your screws will never block, even after a complete season in the rain. "
🎓 TUTO: Mounting and Maintenance
-
Cleaning the thread: Before mounting, pass a blow of blower in the tapped hole to evacuate the old oil or the metal residues.
-
Manual approach: Always start screwing by hand on the first 3 or 4 turns to be sure not to engage the screw.
-
Cross clamping: For housings, always tighten the screws gradually by following a cross scheme to avoid deforming the central seal.
-
Visual control: If you see that the screw head begins to be marked or the hex footprint turns off, replace it immediately. A screw blocked with a messed footprint is a mechanical nightmare.
✅ Features
-
Reference Rotax : 241231
-
Type: CHC (hollow hexagonal cylindrical) / BTR
-
Dimensions: M6 (diameter) x 45 mm (length)
-
Class: 8.8 (High Resistance)
-
Finish: Elzn (white / white electrozing)
-
Compatibility: Rotax 125 Max, Junior, Senior, Master, DD2.
Note Magickart: Room sold individually. It is always prudent to have some in advance in its box to replace a screw marked during an unforeseen revision.
RX241821
Specific References
in the same category
Customers who bought this product also bought:
The CHC M6X45 VIS (ref. 241231) is a high-strength screw used mainly for the assembly of the motor crankshafts or fixing devices on the block Rotax. His classification 8.8 guarantees excellent resistance to traction and shear, while its surface treatment Elzn (Electrozing) sustainably protects against moisture-related corrosion and track projections.
