Combustion Chamber KZ-R2 3.4 TMKART

Tmkart CYL.61mm

The Four-hole exhaust seal Provides the critical link between the cylinder exhaust light and the flange (or the collector). On a 2-time competition engine like the Tmkart, the slightest leak at this level disrupts the return wave of the exhaust jar, resulting in an immediate loss of torque and the callamine projections on the bottom of the motor.

The Copper cylinder head gasket 0.03 mm is a piece of mechanical goldsmith. Intended for the most advanced competition settings, it adjusts the squish At its limit value when standard thicknesses (0.10 or 0.05 mm) are too important for the desired room volume.

At this thickness, the seal acts almost as a direct contact interface, offering the best possible thermal conductivity between the cylinder and the cylinder head dome.2 0.03

Adjust the compression ratio and the dynamic behavior of your gearbox engine with the Combustion chamber (cylinder head dome) origin TM Kart for KZ-R2 and KZ-R3 engines. Key element of the high motor, the profile of this dome directly determines the volume of the chamber, the height of SQUISH and the combustion speed of the air / gas mixture.

CNC machined with micrometric precision in the workshops of the Italian factory TM Kart, this room guarantees optimal thermal dissipation and a perfect centering in your cylinder head. Proposed in different variations ranging from 3.3 to 3.6, it adapts both on the block Kz-r2 only on the last Kz-r3. It allows you to change your motorization according to your needs: lower dimensions (3.3 / 3.4) To promote explosion, couple and slow turn output, up to higher ratings (3.5 / 3.6To release the top plans, offer an exceptional straight line and prevent the risk of hot weather detonation.

Maximize the ignition efficiency and power of your engine thanks to the bougie BRISK SILVER L08S ignition. Specially developed for the extreme requirements of motorsport and competition karting, this bougie is a real reference for exploiting all the potential of the trademark engines Tm kart (Categories KZ with gearbox and monovynesses).

Its peculiarity lies in the use of a Central electrode in pure silver. Money is the best electricity and heat conductor of all metals (even exceeding platinum and iridium). This property allows the BRISK L08S to deliver a spark of a remarkable energy with a lower voltage, while dissipating the heat accumulated in the high speed combustion chamber. This results in a faster flame start, a more homogeneous combustion of the air / gas mixture and an extremely frank accelerator response throughout the range of use of your TM block (KZ10 to the latest KZ-R3).

Product Full Description: Original TM Kart Furnishing Chamber - For KZ-R2 & KZ-R3 Engines - Sizes 3.3 to 3.6

Adjust the compression ratio and the dynamic behavior of your gearbox engine with the Combustion chamber (cylinder head dome) origin TM Kart for KZ-R2 and KZ-R3 engines. Key element of the high motor, the profile of this dome directly determines the volume of the chamber, the height of SQUISH and the combustion speed of the air / gas mixture.

CNC machined with micrometric precision in the workshops of the Italian factory TM Kart, this room guarantees optimal thermal dissipation and a perfect centering in your cylinder head. Proposed in different variations ranging from 3.3 to 3.6, it adapts both on the block Kz-r2 only on the last Kz-r3. It allows you to change your motorization according to your needs: lower dimensions (3.3 / 3.4) To promote explosion, couple and slow turn output, up to higher ratings (3.5 / 3.6To release the top plans, offer an exceptional straight line and prevent the risk of hot weather detonation.

The 320 mm base gasket is the thickness "pivot" for any engine mechanic. Thicker than the 0.10 mm, it makes it possible to substantially raise the cylinder to release the high regimes by increasing the opening diagrams.

This seal is designed to fit perfectly to the casings of the competition line Kz10b, r1, r2 and brand new r3. Its manufacturing quality guarantees perfect sealing at the base of the cylinder, critical point to avoid any air intake that could deplete your carburation

The 0.30 mm base gasket is an important thickness in the adjustment range Tmkart. By raising the three tenths cylinder, you move the opening times of your transfers and your exhaust light up.

This is the privileged setting for fast circuits with long straight lines because it allows the engine to "better breathe" in the towers. This seal is perfectly compatible with the entire line of gear motors: KZ10B, R1, R2 and the new R3

The 310 mm base gasket is a fundamental technical piece for the preparation of your engine Kz10b. Unlike the cylinder head gasket that can only affect the compression, the base gasket changes the cylinder position with respect to the crankshaft.

At 0.10 mm, this seal is ideal for stalking your diagrams (opening of intake and exhaust lights) with extreme finesse. It is often used alone or stacked with other thicknesses to reach the value of squish and the perfect opening times.

Guarantee the absolute maintenance of your high-engine thanks to theOriginal TM KART CH12 Cylinder Cylinder Nut. Essential Assembly Part on Italian Trademark Competition Engines, this reinforced nut ensures the locking of your cylinder on the motor housings as well as the closing of your cylinder head.

On the Official Exploded View (Tavola 1 - Cylinder and Engine Head KZ-R3 Total Black), this nut carries the Landmark n ° 20. Its integrated-specific base (enlarged flange) allows to spread the clamping pressure in a perfectly uniform manner around the stud (marker 21), avoiding crushing or marking the aluminum range of the cylinder (marker 12) or the Cylinder head. Footprint CH12 (12 mm key) Offers an excellent grip for your torque tools during high-engine revision operations.
